| Camera |
|
| Image Sensor |
1/1.8″CMOS |
| Min. Illumination |
Color:0.0001Lux@(F1.0,AGC ON),B/W:0Lux with IR |
| Shutter Time |
1s-1/100000s |
| WDR |
120dB |
| S/N |
>42dB |
| Angle Adjustment |
0-360°;0-90°;0-360° |
| Lens |
|
| Lens Type |
Fixed |
| Focal Length |
4mm |
| Lens Mount |
M16 |
| Aperture Range |
F1.0,Fixed |
| Field of View |
94.5°(H);50.2°(V);110.2°(D) |
| DORI Distance |
Detect:80m
Observe:31.7m
Recognize:16m
Identify:8m |
| Illuminator |
|
| White LEDs |
4 |
| Whitelight Distance |
15m |
| Compression Standard |
|
| Video Compression |
S+265/H.265/H.264B/H.264M/H.264H/Motion JPEG |
| Video Bit Rate |
32k-16Mbps |
| Audio Compression |
G.711A/G.711U/ADPCM_D/AAC_LC |
| Audio Sampling Rate |
8kHz/32kHz/48kHz |
| Image |
|
| Max. Resolution |
2688×1520@30fps |
| Main Stream |
PAL:25fps(2688×1520,2560×1440,2304×1296)
50fps(1920×1080,1280×720)
NTSC:30fps(2688×1520,2560×1440,2304×1296)
60fps(1920×1080,1280×720) |
| Sub Stream |
PAL:25fps(704×576,704×288,352×288,640×360)
NTSC:30fps(704×480,704×240,352×240,640×360) |
| Third Stream |
PAL:25fps(1280×720,704×576,704×288,352×288)
NTSC:30fps(1280×720,704×480,704×240,352×240) |
| BLC |
Yes |
| HLC |
Yes |
| AGC |
Yes |
| 3D DNR |
Yes |
| White Balance |
Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium
lamp/Incandescent lamp/Locked white balance |
| ROI |
8 regions |
| Corridor mode |
Yes |
| EIS |
N/A |
| OSD |
5 regions; 16*16/32*32/48*48/64*64/96*96 |
| Picture Overlay |
1 region; 200*200 BMP 24bits |
| Privacy Mask |
4 regions |
| Defog |
Yes |
| Feature |
|
| Alarm Trigger |
Motion Detection;Mask Alarm;Voltage Alarm;Disk Full;Disk R/W Error;IP Address Conflict;MAC Address Conflict;FTP Server Exception |
| Video Analytics |
Human/Vehicle Classification;Tripwire;Perimeter |
| Rules of behavior
analyse in 1 scene |
7 |
| Early Warning(EW) |
N/A |
| Linkage Method |
send emailtrigger recording;trigger capture;notify surveillance center |
| Network |
|
| ANR |
ANR |
| Protocols |
HTTP;HTTPS;TCP/IP;UDP;UPnP;ICMP;IGMP;N/A;SNMP;DHCP;DNS;DDNS;Easy DDNS;NTP;SMTP;SSL;802.1X;QoS;IPv4;IPv6;N/A;PPPOE;N/A;SSH;Unicast;Multicast;RTCP;ARP;RTP;SRTP;RTSP;FTP;SFTP;NAS |
| System Compatibility |
onvif Profile S/T/G/M;CGI;MILSTONE;RTMP |
| Remote Connection |
≤2 |
| Client |
Easy7 Smart Client |
| Moblie Client |
EasyLive Plus |
| Web |
IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+ |
| Interface |
|
| Communication
Interface |
1RJ45,10M/100M self adaptive Ethernet port |
| Audio I/O |
N/A |
| Alarm I/O |
N/A |
| Built-In Mic |
Yes |
| Built-In Speaker |
N/A |
| Reset Button |
Yes |
| On-board storage |
Built-in Micro SD card slot, up to 512GB |
| General |
|
| Web Client Language |
19languages
Simple Chinese/TraditionalChinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/Polish/Dutch
/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese/Albanian |
| Operating Temperature |
-40℃-65℃ |
| Operating Humidity |
0-95%(non-condensing) |
| Storage Temperature |
-40℃-65℃ |
| Storage Humidity |
0-95%(non-condensing) |
| Power Supply |
DC12V±25%,MAX 8.5W;POE 802.3at,MAX 9.5W |
| Protection |
Surge protection 2000V;Lightning proof 6000V;IP67;N/A |
| Boundary Dimensions |
239(L)90(W)90(H)mm |
| Package Dimensions |
280(L)125(W)140(H)mm |
| GrossWeight |
1.28kg |
| NetWeight |
0.92kg |
