2MP Dual TC-C32RN Turret I5/E/Y/QX/2.8mm/V4.2

  • Dual Lense,Dual Sensor,One IP Two Channel
  • Plastic Housing
  • Up to 1920×1080@30fps
  • S+265/H.265/H.264
  • Min. illumination Color: 0.02Lux@F1.6
  • Smart IR, IR Range: 50m
  • Built-in Mic
  • Operating Conditions -30°~60°, 0~95% RH
  • DC12V,POE(802.3af)
  • IP67
SKU: TC-C32RN

Description

Date Title Type Download
2023-09-15 TC-C32RN SpecI5EYQX2.8mmV4.2 pdf
Camera
Image Sensor 1/3″CMOS
Min. Illumination Color:0.02Lux@(F1.6,AGC ON),B/W:0Lux with IR
Shutter Time 1s-1/100000s
Day&Night IR-cut filter with auto switch (ICR)
WDR DWDR
S/N >36dB
Angle Adjustment 0-350°;0-90°;0-360°
Lens
Lens Type Fixed
Focal Length 2.8mm
Lens Mount M12
Aperture Range F1.6,Fixed
Field of View 93.9°(H);51.2°(V);107°(D)
DORI Distance Detect:42.26m
Observe:16.77m
Recognize:8.45m
Identify:4.23m
Illuminator
IR LEDs 6
IR Distance 50m
Wavelength 850nm
White LEDs N/A
Whitelight Distance N/A
Compression Standard
Video Compression S+265/H.265/H.264B/H.264M/H.264H
Video Bit Rate 32k-4Mbps
Audio Compression G.711A/G.711U
Audio  Sampling Rate 8kHz/16kHz
Max. Resolution 1920×1080@30fps
Main Stream PAL:
25fps(1920×1080,1280×720,640×480,704×576)
NTSC:
30fps(1920×1080,1280×720,640×480,704×480)
Sub Stream PAL:25fps(704×576,704×288,640×360,352×288)
NTSC:30fps(704×480,704×240,640×360,352×240)
Third Stream N/A
BLC Yes
HLC Yes
AGC Yes
3D DNR Yes
White Balance Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium lamp/Incandescent lamp/Locked white balance
ROI N/A
Corridor mode N/A
EIS N/A
OSD 1region;16*16/32*32/48*48
Picture Overlay N/A
Privacy Mask 4 regions
Defog Yes
Feature
Alarm Trigger Motion Detection;IP Address Conflict
Linkage Method trigger
capture
Video Analytics N/A
Rules of behavior analyse in 1 scene N/A
Early Warning(EW) N/A
Auto-Tracking N/A
Face Mode N/A
Face Detection Performance N/A
Network
ANR N/A
Protocols HTTP;TCP/IP;UDP;ICMP;DHCP;DNS;NTP;IPv4;SSH;Unicast;RTSP;FTP
System Compatibility P2P(Mutually exclusive with Profile G);onvif Profile S/T;CGI;MIL STONE
Remote Connection ≤2
Client Easy7 Smart Client
Moblie Client EasyLive Plus
Web IE10+;Firefox52+;Edge89+;Safari11+;Chrome57+
Interface
Communication Interface 1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O N/A
Alarm I/O N/A
Built-In Mic Yes
Built-In Speaker N/A
Reset Button N/A
On-board storage N/A
Additional interfaces N/A
General
Web Client Language 18languages
Simple Chinese/Traditional Chinese/English/Spanish/Korean/Italian/Turkish/Russian/Thai/French/Polish/Dutch/Hebrew/Arabic/Vietnamese/German/Ukrainian/Portuguese
Operating Temperature -30℃-60℃
Operating Humidity 0-95%
Storage Temperature -30℃-60℃
Storage Humidity 0-95%(non-condensing)
Power Supply DC12V±25%,MAX 7.5W;POE 802.3af,MAX 8.5W
Protection Surge protection 2000V;Lightning proof 6000V;IP67
Boundary Dimensions 260(L)133(W)115(H)mm
Package Dimensions 315(L)145(W)140(H)mm
GrossWeight 0.87kg
NetWeight 0.67kg





Additional information

Weight 0.500 kg
Housing

Camera Resolution

Lens

Series

Microphone

WDR
